Features

• Self-priming design - once pump is initially primed, filled with water, it will reprime when the water level rises above the end of the suction pipe
• Back pullout design allows disassembly of pump for service without disturbing piping
• Two compartment motor for easy access to motor wiring and replaceable components
• Bolt down diffuser (guidevane) provides positive alignment with impeller. F.D.A. compliant, injection molded, glass filled Lexan for durability and abrasion resistance
• Corrosion and abrasion resistant, glass filled Noryl impeller, F.D.A. compliant
• Electro-coat paint process is applied inside and out, then baked on for corrosion resistance
• Cast iron casing, 4-bolt, back pull-out design. Openings for vacuum gauge and casing drain
• Powered for continuous operation
• Rated within the motor manufacturer’s recommended working limits
• Can be operated continuously without damage
• Mechanical seal with carbon/ceramic faces, BUNA elastomers. 300 series stainless steel metal parts
• Diaphragm prevents the seal from running dry
• NEMA standard open drip proof motor
• Stainless steel shaft
• Overload protection must be provided in starter unit
• Starter and heaters (3) must be ordered separately
